White paper: Introducing Lprobes® and XLprobes® technology for Atomic Force Microscopy

Résumé

We present a new MEMS (MicroElectroMechanical Systems) fabrication process enabling batch production of in-plane Atomic Force Microscopy (AFM) probes with very high lengths and high aspect ratios. This process enables to introduce two probe series: Lprobe® featuring 30 to 40 µm tip lengths, and XLprobe® with tip lengths above 100 µm. These long, high-aspect-ratio probes are fully compatible with standard AFM systems and offer prospects for enhanced imaging range and spatial resolution in topography. We also discuss about benefits that long tips should bring regarding Electrostatic Force Microscopy (EFM), Kelvin Probe Force Microscopy (KPFM), and Piezoresponse Force Microscopy (PFM). Finally, we describe the advantages expected in infrared nanospectroscopy (AFM-IR) and scattering-type Scanning Near-Field Optical Microscopy (s-SNOM).

Fichier principal
Vignette du fichier
White paper - Introducing Lprobes and XLprobes technology for Atomic Force Microscopy techniques - 01092025.pdf (659.08 Ko) Télécharger le fichier
Origine Fichiers produits par l'(les) auteur(s)
Licence
DOI

Cite 10.5281/zenodo.17463161 Article Walter, B., & Faucher, M. (2025). White paper: Introducing Lprobes® and XLprobes® technology for Atomic Force Microscopy. Zenodo. https://doi.org/10.5281/ZENODO.17463161

Dates et versions

hal-05326123 , version 1 (22-10-2025)

Licence

Identifiants

Citer

Benjamin Walter, Marc Faucher. White paper: Introducing Lprobes® and XLprobes® technology for Atomic Force Microscopy. 2025, ⟨10.5281/zenodo.17463161⟩. ⟨hal-05326123⟩
