Pré-Publication, Document De Travail (Preprint/Prepublication) Année : 2025

Netting and Background Distinction with In-Flight Optic Flow

Résumé

Web-like obstacles, such as safety nets, represent a unique hazard for drones, and especially UAVs (Unmanned Aerial Vehicles). Fencing and netting are particularly difficult to distinguish from the background using either computer vision, lidar and sonar. In contrast, animals such as flying insects may detect these web-like obstacles using Optic Flow (OF), and more precisely motion parallax. A netting-avoidance solution was proposed using a OF-based detection method. The detection method was based on a signature defined by the shape of the OF magnitude across the visual field. We established that the OF shape depends on the orientation of the netting in relation to the hexarotor's movement. This paper demonstrates netting detection in real-world experiments, according to any direction flight made by the UAV along the net. The proposed method separates the OF signatures belonging to these different surfaces -netting or backgroundwhatever their orientations. By extracting the OF signatures of these different surfaces and separating them, the proposed visual method can estimate their relative locations and orientations. In a robotic simulations, the multirotor explores and navigates automatically using this netting detection method, using saccades to avoid obstacles. In the simulations, these saccades are also used to simplify netting detection by orienting itself systematically parallel to these planes, a behavior reminiscent of flying insects

Fichier principal
Vignette du fichier
Netting_and_Background_Distinction_with_In-Flight_Optic_Flow (2).pdf (26.32 Mo) Télécharger le fichier
Supplemental_Informations.pdf (10.79 Mo) Télécharger le fichier
Origine Fichiers produits par l'(les) auteur(s)
Licence
Format Autre
Origine Fichiers produits par l'(les) auteur(s)
Licence
Commentaire Supplemental Information
Recherche Data Gouv

A comme partie 10.57745/DZIM2L Jeu de données DAINI, Xavier, 2024, "Camera images from embedded Camera on a drone flying in front of walls and nettings in simulation and experimental data", https://doi.org/10.57745/DZIM2L, Recherche Data Gouv, V1

Dates et versions

hal-04966013 , version 1 (25-02-2025)
hal-04966013 , version 2 (08-04-2025)
hal-04966013 , version 3 (19-11-2025)

Licence

Identifiants

  • HAL Id : hal-04966013 , version 1

Citer

Xavier Daïni, Romain Raffin, Thibaut Raharijaona, Franck Ruffier. Netting and Background Distinction with In-Flight Optic Flow. 2025. ⟨hal-04966013v1⟩
