Article Dans Une Revue IEEE Photonics Journal Année : 2018

Water Cladded Plasmonic Slot Waveguide Vertically Coupled With Si3N4 Photonics

Résumé

We demonstrate a water cladded plasmo-photonic waveguide, by exploiting the directional coupling scheme to vertically divert light from a 360 × 800 nm (height × width) Si3N4 waveguide to a plasmonic slot waveguide, enabling the excitation of a pure plasmonic mode within a 210-nm-wide slot at 1550 nm. The 150-nm-thick plasmonic slot waveguide was deposited on the top of an oxide cladded Si3N4 waveguide exhibiting an experimental plasmonic-to-photonic insertion loss of 2.24 ± 0.3 dB and a plasmonic propagation length (Lspp) of 10.8 μm at 1550 nm. The proposed plasmo-photonic waveguide holds a promise as an optical transducer element for highly sensitive and low-cost interferometric biosensors due to the significant phase change achieved per unit propagation length.

Fichier principal
Vignette du fichier
08353831.pdf (881.92 Ko) Télécharger le fichier
Origine Publication financée par une institution

Dates et versions

hal-03543138 , version 1 (14-04-2025)

Identifiants

Citer

George Dabos, Dimitra Ketzaki, Athanasios Manolis, Evaggelia Chatzianagnostou, Laurent Markey, et al.. Water Cladded Plasmonic Slot Waveguide Vertically Coupled With Si3N4 Photonics. IEEE Photonics Journal, 2018, 10 (3), pp.2700308. ⟨10.1109/JPHOT.2018.2832461⟩. ⟨hal-03543138⟩
