Adequate Inner Bound for Geometric Modeling with Compact Field Function - Archive ouverte HAL Access content directly
Journal Articles Computers and Graphics Year : 2013

Adequate Inner Bound for Geometric Modeling with Compact Field Function

Abstract

Recent advances in implicit surface modeling now provide highly controllable blending effects. These effects rely on the field functions of $\mathbb{R}^3 \rightarrow \mathbb{R}$ in which the implicit surfaces are defined. In these fields, there is an outside part in which blending is defined and an inside part. The implicit surface is the interface between these two parts. As recent operators often focus on blending, most efforts have been made on the outer part of field functions and little attention has been paid on the inner part. Yet, the inner fields are important as soon as difference and intersection operators are used. This makes its quality as crucial as the quality of the outside. In this paper, we analyze these shortcomings, and deduce new constraints on field functions such that differences and intersections can be seamlessly applied without introducing discontinuities or field distortions. In particular, we show how to adapt state of the art gradient-based union and blending operators to our new constraints. Our approach enables a precise control of the shape of both the inner or outer field boundaries. We also introduce a new set of asymmetric operators tailored for the modeling of fine details while preserving the integrity of the resulting fields.
Fichier principal
Vignette du fichier
SMI2013_Canezin_et_al.pdf (3.54 Mo) Télécharger le fichier
Vignette du fichier
Origin Files produced by the author(s)
Format Figure, Image
Loading...

Dates and versions

hal-00833576 , version 1 (14-06-2013)
hal-00833576 , version 2 (17-06-2013)

Identifiers

Cite

Florian Canezin, Gaël Guennebaud, Loic Barthe. Adequate Inner Bound for Geometric Modeling with Compact Field Function. Computers and Graphics, 2013, 37 (6), pp.565--573. ⟨10.1016/j.cag.2013.05.024⟩. ⟨hal-00833576v2⟩
