Article Dans Une Revue IEEE Transactions on Magnetics Année : 2014

Homogenization Methods in Simulations of Transcutaneous Energy Transmitters

Résumé

Transcutaneous Energy Transmitters (TETs) transfer wireless energy through an inductive link established between two pancake coils placed, respectively, outside and inside the body of a patient. The simulation of the misalignment between the coils must be performed in three dimensions (3D), e.g., with a Finite Element (FE) method. This paper introduces a homogenization method to minimize the cost of the expensive 3D FE computation in the frequency domain. Its originality lies in the non-homogeneous TET geometry during the meshing process. The results of this technique are compared with those obtained by considering regular stranded TET coils. They showed improvements mainly at kilohertz frequencies, the typical TET operating frequency range

Fichier principal
Vignette du fichier
DWolter_homog_measurements_Cmag2013_Full_preprint.pdf (710.4 Ko) Télécharger le fichier
Origine Fichiers produits par l'(les) auteur(s)
Licence

Dates et versions

hal-00869995 , version 1 (20-12-2024)

Licence

Identifiants

Citer

Daniela Wolter Ferreira, Ruth V. Sabariego, Luiz Lebensztajn, Laurent Krähenbühl, Florent Morel, et al.. Homogenization Methods in Simulations of Transcutaneous Energy Transmitters. IEEE Transactions on Magnetics, 2014, 50 (2), pp.7025204. ⟨10.1109/TMAG.2013.2284891⟩. ⟨hal-00869995⟩
